Portable touchscreen tester that quickly verifies copper and fiber cabling performance with clear graphical pass/fail indicators for faster and more accurate job completion.
Performs rapid wiremap, length, and attenuation measurements, along with PoE verification and basic LAN connectivity checks to detect and diagnose faults directly on-site.
Features intuitive templates, automatic test naming, and on-device reporting tools that eliminate manual paperwork and simplify client documentation.
Built with a rugged, ergonomic handheld design and extended battery life, allowing technicians to work through full-day testing operations without interruption.
Comes with a reliable two-year manufacturer warranty for the instrument (accessories and consumables excluded).
Key Features
Capacitive touchscreen with simple, menu-based interface
Fast wiremap and cable length testing
Fiber loss checks with optional adapters
PoE and LAN connectivity (ping/UDP) tests
On-device reports and auto test templates
USB export and optional cloud sync
Rugged, long-life rechargeable design
Compact, one-handed operation with remote IDs
Two-year warranty (instrument only)
The SignalTEK CT with touchscreen is a next-generation cable performance tester designed for professional network installers and system integrators who need reliable proof-of-performance documentation. It verifies copper and fiber cabling by simulating real Ethernet data transmission up to Gigabit speeds ensuring every link supports the required bandwidth before network activation. The tester identifies wiring faults such as opens, shorts, and split pairs, while also measuring cable length, signal attenuation, and Power-over-Ethernet (PoE) availability. Its bright, glove-friendly touchscreen and intuitive interface make it ideal for demanding environments, providing immediate visual results without the need for additional configuration or a PC connection.
Built for durability and precision, the SignalTEK CT offers automated test sequences, easy result naming, and PDF/CSV report generation directly from the device perfect for certification-style documentation and client handovers. It supports multiple languages, integrates with IDEAL DataCENTER software for cloud storage, and allows export via USB for simplified project management. The rugged design, long-lasting lithium battery, and solid-state memory make it dependable for field technicians who require consistent performance. Backed by a two-year manufacturer warranty (main unit only; accessories excluded), the SignalTEK CT ensures long-term reliability and cost-efficient ownership for network verification tasks across commercial, industrial, and enterprise installations.
| Specification | Details |
|---|---|
| Display | Capacitive color touchscreen (example size: ~4.3″ — check official datasheet for exact) |
| Supported Tests | Wiremap, length, split-pair detection, attenuation, PoE detection, basic LAN connectivity (ping) |
| Ports | RJ-45 for copper; optional fiber adapter modules for LC/SC |
| Data Storage & Export | Internal test log memory; USB mass storage (CSV); on-device reports; optional cloud sync |
| Battery | Rechargeable Li-ion; full-shift runtime typical; replaceable/optional spare available |
| Mechanical | Handheld form factor, rugged enclosure for field use (see datasheet for dimensions & weight) |
| Operating Conditions | Typical field range: 0°C to 50°C (refer to official spec for extended ranges) |
| Compliance | Meets common cabling test standards and safety certifications (refer to certificate) |
| Warranty | Two-year manufacturer warranty for the main instrument (must be ordered at purchase). Accessories excluded. |
| Accessory | Purpose / Benefit | Notes / Part |
|---|---|---|
| Remote Test IDs / Remotes | Enable two-ended wiremap and length testing for end-to-end verification | Remote ID kit (sold separately) |
| Fiber Adapter Modules | Add singlemode/multimode LC or SC connectors for basic continuity and loss checks | LC / SC adapters (optional) |
| Certified Patch Cord Set | Reference cables for verification and periodic calibration checks | Cat5e / Cat6 / Cat6A sets available |
| Hard Carry Case | Protects tester and accessories in transit; organizes remotes and leads | Foam-insert rugged case |
| Desk Charging Cradle & Spare Battery | Faster charging and hot-swap capability for extended field uptime | Optional accessory pack |
| Calibration & Service Plan | Annual calibration, priority repairs and extended warranty options | 1- and 3-year plans available (accessories not covered) |
