Key Features:
LanTEK IV-S 500MHz certifier with permanent link and channel adapters
FiberTEK IV MM LED and SM Laser Kit for LC MM 50/125μm & LC SM 9/125μm
FiberMASTER Quad OTDR with multimode and singlemode launch cables (SC-SC, SC-LC)
FiberMASTER Video Inspection Probe for reliable end-face quality checks
Complete with 3-Year Sapphire Care Plan for protection and support
The LT4-500FOS-3Y bundle is a professional-grade certification and testing solution designed for both copper and fiber optic networks. At its core, it features the LanTEK IV-S 500MHz certifier, capable of performing permanent link and channel certification, wiremap, length, propagation delay, NEXT, FEXT, return loss, and insertion loss measurements. Its compatibility with TIA, ISO, and IEC standards ensures reliable results for Cat5e, Cat6, and Cat6A installations. The integrated permanent link and channel adapters, combined with a color touchscreen interface and reporting software, streamline testing processes and provide clear, accurate documentation for all structured cabling projects.
For comprehensive fiber testing, the bundle includes the FiberTEK IV MM LED and SM Laser Kit supporting both multimode (LC 50/125μm) and singlemode (LC 9/125μm) networks, along with the FiberMASTER Quad OTDR offering precise event detection, splice loss analysis, and length measurements. Multiple launch cables for both multimode and singlemode fibers ensure accurate OTDR results, while the FiberMASTER Video Inspection Probe allows quick end-face inspection with pass/fail indication. The package is completed with essential accessories and a 3-year Sapphire Care Plan, providing repair, replacement, and service coverage, making this bundle an all-in-one, reliable solution for professional network deployment and maintenance.
| Component | Model / Item | Detailed Specifications |
|---|---|---|
| Certifier | LanTEK IV-S 500MHz | Test bandwidth: 500 MHz Test types: Permanent link and channel certification, wiremap, length, propagation delay, NEXT, FEXT, return loss, insertion loss Standards: TIA / ISO / IEC Cat6A, Cat6, Cat5e Adapters: Permanent link and channel adapters Interface: Color display with touchscreen, USB export Software: Reporting and results management |
| Fiber Test Kit | FiberTEK IV MM LED + SM Laser Kit | Multimode source: LED for 50/125µm (LC) Singlemode source: Laser for 9/125µm (LC) Wavelengths: MM: 850 / 1300 nm, SM: 1310 / 1550 nm Output connectors: LC (MM and SM) Applications: Insertion loss and certification testing |
| OTDR | FiberMASTER Quad OTDR | Wavelengths: MM 850 / 1300 nm, SM 1310 / 1550 nm Functions: Event detection, length, splice loss, reflectance Interface: Color touchscreen, storage, export |
| Launch Cables (Multimode) | OM3, 150 m | Included: 2 × SC–SC, 2 × SC–LC Fiber type: 50/125 µm multimode Purpose: OTDR launch / receive cables |
| Launch Cables (Singlemode) | SM G.657 A1, 150 m | Included: 2 × SC–SC, 2 × SC–LC Fiber type: 9/125 µm bend-insensitive Purpose: OTDR launch / receive cables |
| Video Inspection | FiberMASTER Video Probe | Purpose: Fiber end-face inspection Features: Portable, interchangeable tips (LC, SC, etc.) Indicator: Pass/fail detection on screen |
| Accessories | Included with bundle | Permanent link & channel adapters, fiber connectors, launch cables, inspection tips, cleaning accessories, carry case |
| Service & Support | 3-Year Sapphire Care Plan | Coverage: 3 years Includes: Repair/replacement, service priority, calibration (per plan terms) |
| Accessory | Type / Model | Details |
|---|---|---|
| Permanent Link Adapters | LanTEK IV-S | Used with the certifier to test and certify permanent links in copper cabling installations. |
| Channel Adapters | LanTEK IV-S | Allows testing of channel configurations including patch cords and work area connections. |
| Fiber Launch Cables (Multimode) | OM3 150 m | 2 × SC–SC, 2 × SC–LC; used for OTDR testing to measure near-end events and connector loss. |
| Fiber Launch Cables (Singlemode) | SM G.657 A1 150 m | 2 × SC–SC, 2 × SC–LC; bend-insensitive singlemode fiber for precise OTDR testing. |
| Fiber Connectors | LC MM 50/125µm & LC SM 9/125µm | Included with FiberTEK IV kit for multimode and singlemode testing. |
| Video Inspection Probe | FiberMASTER | Handheld probe with interchangeable tips for LC/SC connectors, ensures clean and defect-free end-faces. |
| Inspection Probe Tips | LC, SC (others may vary) | Interchangeable tips for inspecting different connector types under the video probe. |
| Cleaning Tools | Fiber Cleaning Accessories | Used to maintain clean connector end-faces before testing to avoid false results. |
| Carry Case | Soft/Hard Case | Protective case provided for safe transport and storage of instruments and accessories. |
| Documentation | User Manuals | Guides for LanTEK IV-S, FiberTEK IV, and FiberMASTER OTDR with setup and usage instructions. |
