The INS2032 delivers high-efficiency RF amplification tailored for specific frequency bands used in LTE, 5G, and defense applications.
It provides excellent linearity and low noise, ensuring optimal signal integrity in demanding communication environments.
The unit is designed for DPD compatibility, allowing integration with advanced digital systems for superior performance.
Its rugged and compact form factor makes it suitable for both fixed and mobile deployments in harsh conditions.
Built-in protections like over-temperature and over-voltage ensure safe and reliable operation across extended usage scenarios.
Key FeaturesÂ
High-efficiency RF amplification
Custom frequency band support
Low noise and high linearity
DPD system compatible
Rugged and compact design
Over-temperature and over-voltage protection
Stable and clean output power
Suitable for LTE, 5G, and defense use
The INS2032 Band Specific Power Amplifier is a high-performance RF amplifier designed for efficient and precise signal amplification within defined frequency bands. Engineered to support critical wireless communication applications, it delivers excellent gain, low noise, and stable output power across a broad range of environments. Whether deployed in LTE and 5G infrastructure, defense systems, or RF test setups, the INS2032 provides reliable and consistent amplification with minimal signal distortion. Its compact and durable design makes it ideal for integration into both fixed and mobile platforms, even in challenging operating conditions.
The INS2032 supports customized frequency ranges and is fully compatible with digital predistortion (DPD) technologies, enhancing linearity and spectral performance. Advanced thermal management, rugged connectors, and protection features such as over-voltage and over-temperature safeguards ensure long-term reliability and operational safety. With high power efficiency and smart control interface options, the INS2032 is a dependable solution for RF engineers and system integrators who require powerful, efficient, and precise amplification for mission-critical band-specific systems.
| Parameter | Specification |
|---|---|
| Frequency Range | Customizable (e.g., 2496–2690 MHz) |
| Bandwidth | Up to 60 MHz |
| Gain | ≥ 48 dB |
| Gain Flatness | ±1.0 dB |
| Output Power (P1dB) | ≥ 46 dBm (40 W) |
| Power Added Efficiency | ≥ 38% |
| Input Return Loss | ≥ 15 dB |
| Output Return Loss | ≥ 12 dB |
| Harmonics | ≤ –45 dBc |
| Intermodulation Distortion | ≤ –30 dBc @ 2-tone, 1 MHz spacing |
| Noise Figure | ≤ 5 dB |
| DPD Compatibility | Yes |
| Power Supply | 28 VDC |
| Current Consumption | ≤ 7 A |
| Cooling | Passive or active cooling |
| Operating Temperature | –20°C to +60°C |
| Storage Temperature | –40°C to +85°C |
| Dimensions | 160 × 110 × 35 mm |
| Weight | Approx. 1.3 kg |
| RF Connector Type | SMA or N-Type (female) |
| Protection Features | Over-temperature, over-voltage, reverse polarity |
| Compliance | CE, FCC, RoHS |
| Accessory | Description | Quantity | Remarks |
|---|---|---|---|
| DC Power Cable | Shielded power cable for 28V DC input | 1 | Standard length 1.5 meters |
| RF Coaxial Cable | High-quality SMA or N-type RF cable | 1 | Connector type matches amplifier port |
| Mounting Brackets | Metal brackets for secure installation | 2 | Includes screws and washers |
| Cooling Fan Assembly | External cooling fan unit if required | Optional | Recommended for high ambient temps |
| User Manual | Printed installation and operation guide | 1 | Includes safety and compliance notes |
| Control Interface Cable | For remote monitoring or configuration | 1 | Optional depending on model |
| Protective Cover | Dust-resistant cover for storage | 1 | Soft-shell material |
