INS2025 Band Specific Power Amplifier

INS2025 Band Specific Power Amplifier

  • Designed for high-efficiency amplification in the 1805–1880 MHz frequency band, ideal for LTE and 5G systems.

  • Delivers robust 25 dB gain with excellent linearity and low noise for clean signal transmission.

  • Compact hybrid IC package with internally matched ports ensures easy integration and space efficiency.

  • Built-in thermal protection and rugged construction allow reliable operation in demanding environments.

  • Optimized for wireless infrastructure, public safety, and mission-critical RF communication applications.

Send Enquiry

Key Features

  • Band-specific design for optimized performance

  • High gain for strong signal amplification

  • Excellent linearity minimizes signal distortion

  • Compact and efficient hybrid IC package

  • Internally matched input and output ports

  • Wide voltage operating range

  • Integrated thermal protection circuitry

  • Rugged design for harsh environments

  • Ideal for LTE, 5G, and RF systems

  • Supports spectral emission compliance

The INS2025 Band Specific Power Amplifier is a high-performance RF amplifier designed to deliver efficient, linear signal amplification within a defined frequency band. Engineered for demanding wireless and communication systems, it offers excellent power output, high gain, and superior linearity, ensuring minimal signal distortion across the entire operating range. The amplifier’s robust design supports seamless integration into infrastructure such as LTE/5G base stations, point-to-point radios, and public safety networks, where consistent performance and reliability are essential.

Built with advanced thermal management and internal protection circuitry, the INS2025 maintains stability under continuous operation and harsh environmental conditions. Its compact form factor and internally matched interfaces simplify the design process, reducing the need for external components. This amplifier is ideal for applications requiring strict compliance with spectral emissions standards, offering a balance of power efficiency, bandwidth precision, and rugged durability. Whether in urban deployments or remote installations, the INS2025 ensures high-quality signal delivery where it matters most.

Specifications

Parameter Specification
Model INS2025
Frequency Range 1805 MHz – 1880 MHz
Gain 25 dB (typical)
Output Power (P1dB) +34 dBm (typical)
Linearity (ACLR) -45 dBc @ +28 dBm average power
Noise Figure 2.8 dB (typical)
Input Return Loss ≥ 12 dB
Output Return Loss ≥ 14 dB
Supply Voltage +28 V DC
Current Consumption 500 mA (typical)
Package Type Hermetically Sealed Hybrid IC
Thermal Protection Built-in with automatic shutdown
Operating Temperature -40°C to +85°C
Applications LTE, 5G, RF Communication, Public Safety



Accessory Description
RF Coaxial Cables High-quality low-loss cables for reliable RF signal connections (SMA/N-type options available).
Power Supply Unit (28V DC) Stable and regulated DC power supply compatible with the amplifier’s input voltage requirements.
Heatsink Assembly Aluminum heatsink designed for passive thermal dissipation during high-power operation.
Cooling Fan Module Optional active cooling solution to maintain optimal temperature under continuous load.
Mounting Kit Includes screws, brackets, and spacers for secure mechanical integration into system enclosures.
EMI Shielding Case Protective enclosure to reduce electromagnetic interference and ensure signal integrity.
Monitoring Interface Board Optional module to monitor operating temperature, voltage, and RF output status.
Surge Protection Device Protects amplifier from power surges, lightning strikes, and transient voltage spikes.
