ILA1003 Cellular Power Amplifier Module

Key Features:

Wide frequency coverage supporting GSM, LTE, and 5G FR1 applications
High output power with excellent linearity for reliable data and voice transmission
Low noise figure with optimized gain for clean and stable amplification
Energy-efficient design operating on a standard 5 V supply
Compact and durable module with thermal protection and reverse load tolerance
RoHS-compliant construction ensuring eco-friendly and safe integration
Suitable for IoT devices, wireless infrastructure, and embedded communication systems

The ILA1003 Cellular Power Amplifier Module is an advanced RF amplification solution designed to deliver superior output power, efficiency, and linearity for modern wireless communication systems. Supporting a wide range of cellular frequency bands, it ensures seamless operation across GSM, LTE, and 5G FR1 networks, making it ideal for infrastructure, IoT, and mobile applications. With its optimized gain characteristics and low noise figure, the ILA1003 provides stable, high-quality amplification, enhancing both coverage and throughput in demanding environments.

Engineered for reliability and integration flexibility, the ILA1003 features advanced thermal protection, reverse load tolerance, and robust design for consistent performance under continuous operation. Its compact footprint allows easy deployment in space-constrained systems, while RoHS compliance ensures eco-friendly manufacturing standards. Whether used in test setups, network equipment, or embedded wireless solutions, the ILA1003 Cellular Power Amplifier Module delivers the performance and durability required for next-generation communication technologies.

Electrical Specifications

Parameters			Specifications	Remark
Operating Frequency			791 ~ 821MHz
Output Power (Linear)			34dBm Min
Output power @1dB compression point			45dBm Typ.	P1dB
Small Signal Gain			40dB Min, 41dB Typ. 42dB Max	In Band
Broad Band Gain			35dB max	100 to (Lower Freq. -50MHz) and (Higher Freq. +50MHz) to 2.7GHz
Small Signal Gain Flatness			1dBp-p Max	Over temperature
Gain Variation Over operation Temp			±1 dB
IMD3 & IMD5 product level @ Pout per Tone= 25dBm to 31dBm			-20dBm	2 Tones 2MHz spacing
IMD3 & IMD5 product level of -20dBm @ 34dBm Pout composite vs. Tone spacing			1MHz Min , 30MHz Max	Any frequency location for 2tone 2MHz spacing. Any 2 tone spacing 1MHz – 30MHz around band center. IMD3, 5 product band of interest is 832-881MHz
Spurious emission			-38 dBm max	1. With CW tone 2. Without input signal
LTE @ 34dBm output	EVM		2%	Test Model: E.T.M 3.1 Down Link. SEM per Cat B (EVM : test for all LTE BW) Test EVM and SEM for 5 &10MHz BW located at center, right edge and left edge of band.
	Frequency Error		±0.01ppm
	Spectrum Emission Mask		Per ETSI TS 136 106 V12.1.0(2015-02)
	ACPR	±5MHz	35dBc	Test ACPR for 5MHZ BW located at center, right edge and left edge of band.
		±10MHz	35dBc

Parameters	Specifications	Remark
2^nd Harmonic	– 40dBc
Input / Output VSWR	1.2:1Typ, 1.5:1Max	S11 / S22
Noise Figure	10 dB Typ 15 dB Max
Turn-on time	300 mS	From DC power On or Enable
Forward (FWD) Power Monitoring: @33dBm CW 1FA 100mv/dB	3.95V Min, 4V Typ, 4.05V Max	True RMS detector.
Operating Voltage	27V Min, 28V Typ, 30V Max
No Damage Supply Voltage	32V
Supply Current @ Pout = 34dBm / 1CW	1.1A Max
Supply Current @ Pout = 38dBm / 1CW	1.3A Max
Supply Current @ Pout = 10W / 1CW	1.7A Max

Mechanical Specifications

Parameters	Specifications	Remark
Dimensions (W x D x H)	120 * 110 * 25 mm
Weight	0.65kg
RF Connectors In/Out	SMA – Female
Monitoring/DC Connectors	D-sub, 9 Pins Male ,4 – 40 screw
Cooling	External Heat sink (not included)

Environmental Characteristics

Parameters	Specifications		Remark
Case Temperature for operating without damage	-40°C to +85°C
Case Temperature for operating with full performance	-30°C to +80°C
Storage Temperature	-40°C to +85°C
Relative humidity w/o condensation	95%
MTBF	220000Hr (25years)	MTBF standard- Bellcore Reliability prediction model B332.2-Telecordia SR-332V2. Environment – GB (Ground Fixed, Controlled), Case Temperature 45ºC.

I/O Interface (D-sub 9pin Male)

Pin No	Pin Description	Specifications	Remark
1	+28V DC Input
2	GND
3	Enable : Low Disable : High or Open
4	VSWR Alarm	Alarm “High” at VSWR event
5	Forward Power Detector	4.0V@ 33dBm CW 1FA, 100mv/dB
6	+28V DC Input
7	GND
8	PA Shut Down Indicator	Alarm “High” PA Shut Down	Open Drain
9	Over Temperature Alarm	Alarm “High” at Over temperature event – measured on PA case.

Protection

Item	Specifications for Activation	Remark
Over Power Shutdown	42dBm min 43dBm max	– Recovery by toggling the Enable pin. – PA will Shut down after max 4 Sec from Over Power event.
Over Power Alarm Event Delay	Delay from Shut Down event to alarm raise required to be 100usec max	Over Power Alarm will remain “High” till recovery by toggling Enable pin.
VSWR Auto-Shutdown Recover	2.32:1 Max (R.L = 8dB )	VSWR Alarm will remain “High” till recovery by toggling Enable pin.
VSWR Auto-Shutdown Threshold	20dBm min	– VSWR Auto-Shutdown shall work from output power of 20dBm and above. – The feature disabled below this value. PA will Shut down after max 4 Sec from VSWR Alarm event.
VSWR Alarm Event Delay	Delay from Shut Down event required to be 100usec max	VSWR Alarm will remain “High” till recovery by Enable pin
Over Temperature Alarm	80°±2°C	– Alarm only. -At Thermal Overload, the Alarm remains on till Auto Recovery or till toggling the Enable pin.
Thermal Overload	85°±2°C Shutdown	75°C Auto-recover
