Key Features:Â
High-efficiency RF amplification for enhanced signal strength
Multi-band support compatible with GSM, LTE, and 5G networks
Compact and robust design for seamless integration
Advanced thermal management for reliable performance under load
Low-noise amplification ensuring stable connectivity
Optimized linearity and gain for improved data throughput
Suitable for IoT devices, wireless infrastructure, and mobile systems
The ILA1002 Cellular Power Amplifier Module is a high-performance RF amplification solution designed to enhance cellular communication reliability and signal strength across a wide range of applications. Built with advanced semiconductor technology, it delivers superior linearity, efficiency, and gain, ensuring stable connectivity in environments where signal integrity is critical. Its compact form factor and robust design make it ideal for integration into wireless infrastructure, IoT devices, and mobile communication systems, where space optimization and energy efficiency are essential.
Engineered for versatility, the ILA1002 supports multiple cellular frequency bands, making it suitable for GSM, LTE, and 5G-enabled platforms. It incorporates advanced thermal management and low-noise amplification, enabling consistent performance under demanding operating conditions. With its reliable output power and seamless integration capabilities, the ILA1002 module provides developers, network operators, and system integrators with a trusted solution for boosting coverage, improving data throughput, and maintaining high-quality communication across diverse deployment scenarios.
| ILA1002 Cellular Power Amplifier Module — Detailed Specifications | |||
|---|---|---|---|
| Parameter | Min | Typical | Max |
| RF Performance | |||
| Supported Bands | 700–960 MHz (Low), 1710–2170 MHz (Mid), 2300–2690 MHz (High); configurable per SKU | ||
| Small-Signal Gain (25 °C) | 28 dB | 31 dB | 34 dB |
| Gain Flatness (per band) | ±1.0 dB | ||
| Output Power @ 1 dB Compression (P1dB) | 26 dBm | 28 dBm | 30 dBm |
| Linear Output Power (LTE, 10 MHz, 64QAM, ACLR ≤ −30 dBc) | 22 dBm | 24 dBm | — |
| EVM (LTE 64QAM @ Pout=24 dBm) | — | ≤ 3.0 % | 3.5 % |
| Noise Figure | — | 3.0 dB | 3.8 dB |
| Third-Order Intercept (OIP3) | 36 dBm | 38 dBm | — |
| Harmonics (2f, 3f) | ≤ −40 dBc @ 24 dBm Pout, 50 Ω, 3GPP mask compliant | ||
| Spurious Emissions | ≤ −47 dBm/MHz (WCDMA/LTE), per region | ||
| Input/Output Impedance | 50 Ω nominal | ||
| VSWR (Input / Output) | ≤ 1.8 : 1 (typical), ≤ 2.0 : 1 (max) | ||
| Power & Efficiency | |||
| Supply Voltage (VDD) | 4.75 V | 5.0 V | 5.25 V |
| Quiescent Current (EN=High, no RF) | 45 mA | 60 mA | 80 mA |
| Current @ Pout 24 dBm | 380 mA | 420 mA | 480 mA |
| Power-Added Efficiency (PAE) @ 24 dBm | 18 % | 22 % | — |
| Enable / Disable Time | — | 3 µs | 5 µs |
| Control & Interfaces | |||
| RF Connectors / Ports | RF IN (SMA-F or U.FL), RF OUT (SMA-F); 50 Ω | ||
| Control Pins | EN (Enable), TSSI/DET (Power Detect, analog), VREF/Bias (optional) | ||
| Logic Levels (EN) | Low ≤ 0.4 V | High ≥ 1.8 V | 3.6 V max |
| Power Detector Range | −10 dBm | 0 dBm | +10 dBm |
| Protection & Reliability | |||
| Reverse Power / Load Mismatch Tolerance | Up to 10:1 VSWR at rated Pout with protection engaged | ||
| Thermal Protection (OTP) | Auto-throttle / shutdown at 150 °C (junction), auto-recover at 130 °C | ||
| Over-Current Protection (OCP) | Active; latched shutdown above 800 mA | ||
| ESD Rating (HBM) | ±1 kV | ±2 kV | — |
| Environmental & Thermal | |||
| Operating Temperature (Ambient) | −20 °C | +25 °C | +70 °C |
| Storage Temperature | −40 °C | — | +125 °C |
| Thermal Resistance (Junction-to-Case) | — | 12 °C/W | — |
| Relative Humidity (Non-condensing) | 5 % | — | 95 % |
| Mechanical | |||
| Dimensions (L × W × H) | 45 × 30 × 9 mm (incl. shield, excl. connectors) | ||
| Weight | ≈ 22 g | ||
| Mounting | 4 × M2.5 plated mounting holes; recommended standoff height 6–8 mm | ||
| Shielding | Soldered RF can with ventilation apertures; optional gasket | ||
| Finish | ENIG (Au) on PCB pads; black anodized aluminum heatslug | ||
| Compliance & Certifications | |||
| RoHS / REACH | Compliant | ||
| EMC / Safety | Designed for CE & FCC Part 15 environments; final system certification required | ||
| 3GPP Conformance | Meets 3GPP ACLR/EVM masks for LTE (validation dependent on host system) | ||
| Packaging & Accessories | |||
| Included | ILA1002 module, quick-start guide, 2× heatsink screws, adhesive thermal pad | ||
| Optional | External heatsink, SMA cables, DC power cable, UART-to-USB adapter for logging | ||
| Notes: 1) Typical values @ VDD=5.0 V, 25 °C unless stated. 2) Performance varies by band and matching; verify in final enclosure. 3) Do not exceed absolute maximum ratings. 4) For 5G NR FR1 operation, verify EVM/ACLR with target waveform and bandwidth. |
|||
| ILA1002 Cellular Power Amplifier Module — Detailed Accessories | ||||||
|---|---|---|---|---|---|---|
| Category | Accessory | Part No. (SKU) | Description | Compatibility / Bands | Qty | Notes |
| Power | ||||||
| Power | DC Power Adapter 5V/3A | PSU-5V3A-LOCK | Regulated desktop adapter, 5.5×2.1 mm locking barrel, low ripple <30 mVp-p. | All bands | 1 | Recommended |
| Power | DC Input Cable (bare leads) | CBL-DC21-1M | AWG20, 1 m, 5.5×2.1 mm barrel to tinned leads for bench supplies. | All | 1 | Optional |
| Power | Inline Fuse Holder + 1A Fuse | FUS-1A-KIT | Protects module from overcurrent events during integration. | All | 1 | Safety |
| RF Cabling & Adapters | ||||||
| RF | SMA(M)-to-SMA(M) Coax Cable, 30 cm | RF-SMA-MM-30 | Low-loss RG316, VSWR ≤1.3:1 up to 3 GHz, for RF IN/OUT connection. | 700–2690 MHz | 2 | Core |
| RF | U.FL-to-SMA(F) Pigtail, 15 cm | RF-UFL-SMAF-15 | Adapts internal U.FL to panel-mount SMA for enclosure feed-through. | 700–2690 MHz | 2 | Optional |
| RF | 50 Ω SMA Attenuator Set (3/6/10/20 dB) | ATT-SMA-SET | Precision attenuators, 2 W, for gain staging and test protection. | 700–3000 MHz | 1 set | Lab |
| RF | 50 Ω SMA Terminations (2 W) | TERM-SMA-2W | Load terminations for unused ports and instrumentation. | 700–3000 MHz | 2 | Lab |
| RF | Directional Coupler, 30 dB | DCPL-30DB | Monitor forward power without disturbing line; SMA connectors. | 800–2700 MHz | 1 | Test |
| Antennas | ||||||
| Antenna | Outdoor Omni Antenna, 3 dBi | ANT-OMNI-3DBI | Weatherproof fiberglass, pole mount, N-female; includes N-to-SMA cable. | 700–2700 MHz | 1 | Optional |
| Antenna | Directional Panel Antenna, 8 dBi | ANT-PANEL-8DBI | Improves link budget on fixed point installations; SMA pigtail included. | 1710–2690 MHz | 1 | Optional |
| Thermal Management | ||||||
| Thermal | Aluminum Heatsink (bolt-on) | HSK-ALU-45×30 | Black anodized, fits module footprint, 2× M2.5 screws included. | All | 1 | Recommended |
| Thermal | Thermal Pad, 1.0 mm, 6 W/m·K | THP-1MM-6W | Electrically insulating, high-conductivity interface for heatsink. | All | 1 | Core |
| Thermal | Micro Fan, 30×30×10 mm, 5 V | FAN-30MM-5V | Active cooling for sustained high output power or hot environments. | All | 1 | Optional |
| Mounting & Enclosures | ||||||
| Mounting | Standoff Kit, 6–8 mm (M2.5) | STF-M25-KIT | Brass standoffs, screws, and washers for secure PCB mounting. | All | 1 kit | Core |
| Enclosure | EMI Shielded Enclosure | ENC-RF-S | Conductive gasket, SMA bulkheads, vented for airflow and thermal path. | All | 1 | Optional |
| Hardware | SMA Bulkhead Feed-Through | SMA-BHD-F | Panel-mount pass-through for enclosure walls; includes nut and washer. | All | 2 | Optional |
| Control & Interface | ||||||
| Control | Enable (EN) Breakout Harness | CTL-EN-3PIN | 3-pin JST to flying leads for EN/TSSI/Bias pins to controller. | All | 1 | Optional |
| Control | Level-Shifter Module (1.8↔3.3/5 V) | CTL-LVL-SFT | Safely interfaces logic control lines with host systems. | All | 1 | Optional |
| Telemetry | Power Detector Cable (SMA to BNC) | RF-PD-SMA-BNC | Connects detector output to scope or power meter via BNC. | All | 1 | Test |
| Protection & EMI | ||||||
| Protection | ESD Wrist Strap & Mat Kit | ESD-KIT-1 | Basic ESD safety kit for handling the module and RF cables. | All | 1 | Safety |
| EMI | Ferrite Clip-on Cores (5–7 mm) | EMI-FER-SET | Reduces conducted noise on DC and control wiring. | All | 1 set | Optional |
| Protection | RF Surge Protector (SMA) | RFS-SMA-DC3G | Gas discharge protector for outdoor antenna feeds. | 700–3000 MHz | 1 | Outdoor |
| Test & Measurement | ||||||
| Test | Calibrated Power Meter Sensor | PM-SNSR-3G | Inline RF power measurements for setup and compliance checks. | 10 MHz–3 GHz | 1 | Lab |
| Test | Dummy Load, 50 Ω, 10 W | DL-50R-10W | Safe load for burn-in and continuous power testing. | 700–3000 MHz | 1 | Lab |
| Test | Oscilloscope BNC Kit | OSC-BNC-KIT | Probes and adapters for monitoring detector and control lines. | All | 1 | Optional |
| Documentation & Labels | ||||||
| Docs | Quick-Start Guide (Print) | DOC-QSG-ILA1002 | Printed setup steps, pinout, safety and compliance notes. | ILA1002 | 1 | Included |
| Docs | Mounting Template (1:1) | DOC-MNT-TPL | Drill template for standoffs and SMA bulkhead placement. | ILA1002 | 1 | Optional |
| Labels | Safety & ESD Label Set | LBL-ESD-SFTY | Adhesive labels for enclosure and bench safety markings. | All | 1 set | Optional |
| Bundles & Starter Kits | ||||||
| Kit | Integration Starter Kit | KIT-INT-ILA1002 | Includes PSU, heatsink + pad, 2× SMA cables, standoff kit, quick-start. | All | 1 | Value |
| Kit | Lab Test Kit | KIT-LAB-RF | Attenuator set, terminations, directional coupler, dummy load, BNC cable. | 700–3000 MHz | 1 | Lab |
| Notes: 1) Verify regional band compliance and connector gender before ordering. 2) Outdoor antenna use requires proper lightning/surge protection and grounding. 3) Thermal components are recommended for continuous high-power operation. |
||||||
