150058 RJ45 inserts and tool

Key Features:

Pack contains 10 × Samtec LifeJack RJ45 replacement inserts and 1 × Samtec LifeJack insertion/removal tool.
Genuine Samtec modules manufactured to original equipment specifications.
Gold-plated contact surfaces for low contact resistance and corrosion resistance.
Rated for high insertion/removal cycles (high durability spring contacts).
Tool designed to seat and extract inserts without stressing host connector shells.
Restores mechanical and electrical integrity of RJ45 ports quickly in the field.
Compact kit suited for technicians, field engineers, and service centers.
RoHS-compliant materials and industry-standard quality controls.

The 150058 RJ45 Inserts and Tool pack supplies ten genuine Samtec LifeJack replacement RJ45 inserts together with the Samtec LifeJack insertion/removal tool, specifically prepared for field servicing of LanXPLORER, NaviTEK II, NaviTEK NT, SignalTEK II, SignalTEK CT, SignalTEK NT, UniPRO MGig1 and UniPRO SEL1 instruments. Each LifeJack insert is manufactured to Samtec’s quality standards to restore reliable contact life in RJ45 sockets that have experienced wear, bent contacts, or contamination. The included tool precisely seats and extracts LifeJack modules without risking damage to the host connector, enabling fast, repeatable maintenance operations on active test instruments.

The kit is intended to minimize downtime and extend the service life of installed test equipment by providing a quick, field-capable replacement option. Technicians benefit from a consistent repair procedure: remove the worn insert, install a fresh LifeJack module using the tool, verify continuity and mechanical fit, and return the instrument to service. Robust plating, high contact-cycle ratings, and compatibility across multiple tester platforms make this pack a practical, cost-effective spare-part solution for laboratories, maintenance crews, and field engineers.

Specification	Details
Model	150058 — RJ45 Inserts and Tool (Samtec LifeJack)
Contents	10 × Samtec LifeJack RJ45 replacement inserts; 1 × Samtec LifeJack insertion/removal tool
Compatibility	LanXPLORER, NaviTEK II, NaviTEK NT, SignalTEK II, SignalTEK CT, SignalTEK NT, UniPRO MGig1, UniPRO SEL1, and other Samtec LifeJack-enabled devices
Insert material	Phosphor bronze or equivalent contact spring material with gold plating per industry standard
Plating	Gold over nickel plating on contact surfaces (typical thickness per Samtec spec)
Contact resistance	Low contact resistance typical of factory RJ45 inserts (consult Samtec datasheet for exact value)
Durability / cycle rating	Rated for high insertion/removal cycles (designed for frequent servicing); please refer to Samtec LifeJack datasheet for specific cycle count
Tool type	Precision Samtec LifeJack insertion/removal tool designed to seat/extract modules without stressing connector housings
Operating / storage temperature	Storage: −40 °C to +85 °C; Operating (installed): industry-standard connector temperature ranges (consult host device specification)
Dimensions (insert)	Form factor consistent with LifeJack RJ45 modular inserts — refer to Samtec dimensional drawing for exact measurements
Weight (kit)	Approx. 30–60 g (ten inserts plus tool; actual weight dependent on insert material)
Certifications	RoHS compliant; manufactured to Samtec quality standards
Warranty	Limited warranty against manufacturing defects (term varies by supplier—confirm at time of purchase)
Notes	For exact electrical/mechanical specifications and cycle ratings, consult the Samtec LifeJack product datasheet and the host instrument service manual before installation.

Accessory	Description	Included / Optional
Samtec LifeJack RJ45 inserts	Replacement modular RJ45 contact inserts compatible with Samtec LifeJack receptacles.	Included (10 pcs)
Samtec LifeJack insertion/removal tool	Precision tool for safe seating and extraction of LifeJack inserts without damaging connectors.	Included (1 pc)
Protective pouch	Soft pouch for storing inserts and tool when not in use.	Optional
Spare insert pack	Additional packs of 10 inserts for extended service coverage.	Optional
Calibration / service guide	Step-by-step service instructions and connector verification checklist.	Optional (PDF or printed)
