R164059 - FT III/IV-LC 9/125um F/Optic Cables and Couplers

R164059 – FT III/IV-LC 9/125um F/Optic Cables and Couplers

  • Includes six factory-terminated LC–LC single-mode patch cables (9/125 µm) for immediate deployment, testing, and temporary links anywhere with dependable performance.

  • Supplied with four precision LC–LC double couplers to join cables, extend runs, or create quick temporary connections without splicing.

  • Stored in a compact, lockable pouch that organizes and protects cables and couplers while remaining easy to carry between jobsites and labs.

  • Features rugged strain relief, molded boots, and high-precision connector polishing to minimize handling loss and extend connector life under frequent use.

  • Portable kit ideal for field technicians, commissioning teams, laboratory benches, and troubleshooting tasks requiring reliable, ready-to-use single-mode interconnects.

Send Enquiry

Key Features

  • Single-mode fiber: 9/125 µm core/cladding for standard SM networks.

  • Connector type: LC–LC factory-terminated patch cables; LC–LC double couplers included.

  • Low insertion loss through precision polishing and quality alignment sleeves.

  • Rugged strain relief and molded boots to protect connector-to-cable junctions.

  • Compact lockable pouch with dividers for neat storage and transport.

  • Plug-and-play: no field termination required, ideal for quick test setups.

  • Suitable for OTDR launches, fiber test equipment interconnects, lab use, and temporary links.

The FT III/IV LC Cable Kit is a compact, field-ready single-mode interconnect solution engineered for fast deployment and dependable optical performance. The kit contains six factory-terminated LC–LC patch cables (9/125 µm) and four precision LC–LC double couplers that let technicians create temporary links, extend runs, or connect test instruments without splicing. Each cable uses precision-polished LC connectors and molded strain reliefs to keep insertion loss low and connector life long during repeated field or lab use.

Housed in a rugged, lockable pouch with internal dividers, the kit is ideal for commissioning crews, field technicians, and lab engineers who need a small, portable set of high-quality interconnects for troubleshooting, verification, and temporary installations. The compact footprint makes it simple to carry between jobsites while protecting cables from tangles, dirt, and mechanical stress saving setup time and reducing test variability.

Technical Specifications
Specification Value / Notes
Fiber type Single-mode (9/125 µm)
Connector type LC–LC (both ends on patch cables)
Number of patch cables 6
Number of couplers 4 (LC–LC double couplers)
Typical insertion loss (per mated pair) ≤ 0.3 dB (typical; depends on cleanliness and mating)
Return loss (typical) > 30 dB (PC polish; APC variants available by request)
Operating temperature -20 °C to +70 °C
Storage temperature -40 °C to +85 °C
Cable jacket PVC or LSZH (specify on order)
Cable lengths Standard kit lengths or custom lengths available
Weight (kit) Approx. 150–400 g (depending on cable lengths)
Compliance / Standards Manufactured to industry connector and fiber handling best practices
Accessories Included
Item Quantity Description
LC–LC patch cable (9/125 µm) 6 Factory-terminated single-mode patch cables with molded boots and strain relief
LC–LC double coupler 4 Precision alignment sleeve double couplers for joining two LC connectors
Protective pouch 1 Lockable zip pouch with internal dividers for cables and couplers
Documentation 1 Quick reference and care instructions
