FT III/IV-Encircled Flux 50/125um Cable SC - LC

FT III/IV-Encircled Flux 50/125um Cable SC – LC

  • Encircled Flux (EF) compliant 50/125 μm multimode cable ensures controlled launch conditions for repeatable, comparable loss and attenuation measurements across sites and teams.

  • SC–LC polished terminations provide stable, low-loss connections compatible with a wide range of test instruments and patch panels.

  • Plug-and-play with LanTEK III and LanTEK IV certifiers, integrating seamlessly into established certification workflows to reduce setup time and human error.

  • Rugged jacket and reinforced strain relief protect fiber integrity during frequent transport and field use while preserving optical performance.

  • Ideal for installation verification and troubleshooting, the cable supports ISO/IEC testing practices and helps produce reliable handover documentation that clients and auditors trust.

Send Enquiry

Key Features

  • Encircled Flux (EF) compliant 50/125 μm multimode fiber

  • SC (one end) to LC (other end) polished connectors

  • Designed for use with LanTEK III and LanTEK IV certifiers

  • Ensures repeatable, comparable loss measurements across technicians and sites

  • Ruggedized outer jacket with strain relief for field durability

  • Low insertion loss and high return-loss terminations

  • Supports ISO/IEC 14763-3 recommended practices for multimode testing

  • Supplied with protective dust caps and care instructions

The FT III/IV-Encircled Flux 50/125 μm SC–LC Cable is purpose-built to deliver repeatable, standards-compliant multimode test results for deployment with LanTEK III and LanTEK IV certifiers. Manufactured using 50/125 μm multimode fiber and engineered to meet Encircled Flux (EF) launch requirements, this cable stabilizes the modal power distribution at the source so loss and attenuation measurements are comparable across technicians, instruments, and sites. EF compliance reduces measurement uncertainty and ensures certification results that stand up to QA checks and handover requirements.

Terminated with precision polished SC and LC connectors, the cable offers a low-loss, stable connection ideal for field certification and troubleshooting workflows. Its ruggedized jacket and strain-relief terminations withstand frequent handling and transport while maintaining optical performance. Supplied with connector protection and care guidance, the FT III/IV-EF SC–LC cable is designed to simplify referencing, improve test reproducibility, and accelerate project completion with documentation that adheres to industry best practices.

Parameter Detail
Product Name FT III/IV-Encircled Flux 50/125 μm SC–LC Cable
Fiber Type 50/125 μm multimode, Encircled Flux (EF) compliant
Connector Types SC (one end) to LC (other end), UPC/APC option on request
Compatibility LanTEK III and LanTEK IV certifiers and other EF-capable test instruments
Standards Meets EF launch recommendations and supports ISO/IEC 14763-3 testing practices
Jacket & Construction Ruggedized outer jacket with reinforced strain relief for field durability
Typical Applications Multimode link certification, installation handover, acceptance testing, troubleshooting
Performance Provides controlled modal launch for repeatable loss/attenuation measurements and reduced inter-operator variance
Included Items Cable (SC–LC), dust caps, soft carrying pouch, quick reference sheet
Options Custom lengths, armored or low-loss variants, and alternative connector polish types available on request
Accessory Description Quantity Notes
FT III/IV EF Cable (SC–LC) Encircled Flux compliant 50/125 μm multimode cable 1 SC connector on one end, LC connector on the other
Connector Dust Caps Protective caps for SC and LC ends 2 Prevents contamination during storage and transport
Soft Carrying Pouch Protective pouch for cable storage 1 Keeps cable coiled and protected
Quick Reference Sheet Care, referencing and EF usage guidance 1 Includes best practices for ISO/IEC testing
Cleaning Wipes (optional) Fiber connector cleaning wipes 1 pack Recommended before every connection
