Key Features
The PSP-405 200W Programmable Switching D.C. Power Supply is a compact yet powerful unit designed for precision and versatility in laboratory, industrial, and educational settings. Delivering a maximum output of 40V and 5A, it features high efficiency switching technology that ensures stable and reliable DC power with minimal heat generation. The programmable interface supports USB, RS-232, and optional GPIB communication, allowing seamless integration into automated test setups. A bright LCD display provides clear real-time readouts of voltage, current, and status indicators, while built-in protections such as over-voltage, over-current, and over-temperature safeguard both the power supply and connected devices. With its compact form factor, user-friendly interface, and extensive control capabilities, the PSP-405 is ideal for precise power delivery in a wide range of electronic applications.
PSP-Series Specifications
The specifications apply when the PSP-Series is powered on for at least 30 minutes under +20°C~+30°C.
| PSP-603 | PSP-405 | PSP-2010 | |
| OUTPUT | |||
| Voltage | 0~60V | 0~40V | 0~20V |
| Current | 0~3.5A | 0~5A | 0~10A |
| VOLTAGE REGULATION | |||
| Load | ≦10mV | ||
| Line | ≦0.05% | ||
| CURRENT REGULATION | |||
| Load | ≦5mV | ||
| Line | ≦0.05% | ||
| RIPPLE | |||
| Voltage (mVrms) | ≦20mV | ||
| Current (mVrms) | ≦10mA | ||
| RESOLUTION | |||
| Voltage | 20mV | 10mV | 10mV |
| Current | 2mA | 2mA | 5mA |
| PROGRAM ACCURACY | |||
| Voltage | ± 0.05% rdg ± 4digits | ± 0.05% rdg ± 3digits | ± 0.05% rdg ± 3digits |
| Current | ± 0.1% rdg + 5digits | ± 0.1% rdg + 5digits | ± 0.3% rdg + 10digits |
| READBACK (METER) RESOLUTION | |||
| Voltage | Same as Resolution | ||
| Current | Same as Resolution | ||
| READBACK (METER) ACCURACY | |||
| Voltage | Same as program accuracy | ||
| Current | Same as program accuracy | ||
| PROTECTION | |||
| OVL/OCL/OPL/OTP | |||
| OUTPUT ON/OFF CONTROL | |||
| Yes | |||
| DISPLAY | |||
| LCD | |||
| INTERFACE | |||
| RS-232C (Standard) | |||
| POWER SOURCE | |||
| AC 230V ±15%, AC 115V ±15%, 50/60Hz | |||
| DIMENSIONS & WEIGHT | |||
| 225(W) x 100(H) x 305(D)mm / Approx. 4kg | |||
Accessories
User Manual X 1, Power Cord X 1
Test Lead GTL-104*1 ; European Test Lead GTL-204* 1
Optional Accessories
GTL-232A RS-232C Cable
GRA-428 Rack Mount Kit, 19″, 3U Size
