PLR 60-12 Low Noise D.C. Power Supply

Key Features

Output: 0-60V, 0-12A, 720W
Low ripple and noise for stable power
Programmable for automated testing
Over-voltage, over-current, and over-temperature protection
Ideal for precision testing and development
User-friendly interface for easy control

The PLR 60-12 Low Noise D.C. Power Supply is a highly versatile and reliable programmable power source designed for a wide range of applications in research, testing, and development. With an output capacity of 0 to 60V and 0 to 12A, delivering a total power output of up to 720W, this power supply offers precision and stability for powering sensitive electronic devices and components. The unit is engineered to produce low ripple and noise, ensuring clean and stable power delivery, which is critical for testing high-precision systems. Its programmable features allow for easy integration into automated testing setups, while the user-friendly interface provides intuitive control over voltage, current, and power settings. Additionally, the built-in protection features safeguard against over-voltage, over-current, and over-temperature conditions, ensuring both the safety of the equipment and the devices being powered. This makes the PLR 60-12 an ideal choice for engineers, laboratories, and manufacturing environments where performance and reliability are paramount.

PLR-Series Specifications

The specifications apply when the PLR-Series is powered on for at least 30 minutes under +20°C~+30°C

Model	PLR20-18	PLR20-36	PLR36-10	PLR36-20	PLR60-6
OUTPUT RATING
Voltage	0V to 20V		0V to 36V		0V to 60V
Current	0 ~ 18A	0 ~ 36A	0 ~ 10A	0 ~ 20A	0 ~ 6A
Power	360W	720W	360W	720W	360W
REGULATION (CV)
Load	0.005%FS+2mV		0.005%FS+2mV		0.005%FS+2mV
Line	0.005%FS+1mV		0.005%FS+1mV		0.005%FS+1mV
REGULATION (CC)
Load	5mA		5mA		5mA
Line	5mA	10mA	1mA	5mA	1mA
RIPPLE & NOISE (Noise Bandwidth= 20MHz ; Ripple Bandwidth = 1MHz)
CV p-p	30mVp-p		30mVp-p		30mVp-p
CV rms	0.5mVrms		0.5mVrms		0.5mVrms
CC rms	10mArms		5mArms	10mArms	5mArms	5m Arms
SETTING ACCURACY (23°C±5°C, after 30-minute aging)
Voltage	± (0.5%SET+0.5%F.S):		± (0.5%SET+0.5%F.S):		± (0.5%SET+0.5%F.S):
Current	± (1%SET+1%F.S):		± (1%SET+1%F.S):		± (1%SET+1%F.S):
Power	±(0.7%rdg+1.5%F.S):		±(0.7%rdg+1.5%F.S):		±(0.7%rdg+1.5%F.S):
READBACK ACCURACY (23°C±5°C, after 30-minute aging)
Voltage	±(0.1%rdg+2digit):		±(0.1%rdg+2digit):		±(0.1%rdg+2digit):
Current	±(0.5%rdg+2digit):		±(0.5%rdg+2digit):		±(0.5%rdg+2digit):
RESPONSE TIME
Raise Time	50ms/50ms: No load/Rated load Output voltage: 10%→90%FS		50ms/50ms: No load/Rated load Output voltage: 10%→90%FS		50ms/50ms: No load/Rated load Output voltage: 10%→90%FS
Fall Time(Full load)	50ms ; Output voltage: 90%→10%FS		50ms ; Output voltage: 90%→10%FS		150ms ; Output voltage: 90%→10%FS
Fall Time(No load)	250ms ; Output voltage: 90%→10%FS		250ms ; Output voltage: 90%→10%FS		600ms ; Output voltage: 90%→10%FS
Load Transient Recover Time (Load change from 50 to 100%)	100μs		100μs		100μs
SETTING RESOLUTION
Voltage	10mV		10mV		10mV
Current	10mA		10mA		10mA
MEASUREMENT RESOLUTION
Voltage	10mV		10mV		10mV
Current	10mA		10mA		10mA
SERIES AND PARALLEL CAPABILITY
Parallel Operation	Up to 3 units		Up to 3 units		Up to 3 units
Series Operation	Up to 2 units		Up to 2 units		Up to 2 units
PPROTECTION FUNCTION
OVP	Set range: 10% to 110% FS. Set resolution: 10 times the minimum display resolution. Activated when the output voltage exceeds the set OVP value: Hardware detection.
OCP	Set range: 5% to 110% FS. Set resolution: 10 times of minimum display resolution. Activated when the output current exceeds set OCP value: Software detection.
UVP	Set range: -1V to 110% FS. Set resolution: 10 times the minimum display resolution. Activated when the output voltage falls below the set UVP value: Software detection.
ENVIRONMENT CONDITION

Operation Temp	0℃ to 40℃
Storage Temp	﹣20℃ to 60℃
Operating Humidity	30% to 85% RH (No dew condensation)
Storage Humidity	20% to 85% RH (no dew condensation)
READ BACK TEMP WEFFICIENT
Voltage	±100ppm/℃		±100ppm/℃		±100ppm/℃
Current	±100ppm/℃		±100ppm/℃		±100ppm/℃
OTHER
Power consumption	570VA	1100VA	520VA	1050VA	510VA
Power factor	0.99		0.99		0.99
Coolingmethod	Forced cooling: Fan speed proportionate to the temperature of the internal heat sink.
Power Source	Single-phase 100VAC to 240VAC, 50Hz to 60Hz
Interface	RS-232C/LAN (Standard: ) ; GPIB/USB (option)
Analog Control	Yes
Dimension	139.5 (H) * 140(W) *415.5(D)	139.5 (H) * 210(W) *415.5(D)	139.5 (H) * 140(W) *415.5(D)	139.5 (H) * 210(W) *415.5(D)	139.5 (H) * 140(W) *415.5(D)	139.5 (H) * 210(W) *415.5(D)
Weight	5.2kg	7.5kg	5.2kg	7.5kg	5.2kg
