The INS3153 Broadband Amplifier is engineered for wide frequency coverage, operating from 20 MHz to 1000 MHz, making it suitable for various RF applications.
It delivers a powerful 50 Watts of output with 47 dB gain, ensuring strong, clear, and consistent signal amplification across the entire bandwidth.
Compact in size at 162.56 x 86.36 x 27 mm, it fits easily into limited spaces without compromising performance or reliability.
The amplifier runs efficiently on 28 Volts and 8 Amps, optimized for stable operation and long-term use in technical environments.
Designed for CW, FM, and AM signals, it is ideal for communication systems, industrial setups, and test environments.
Key Features
Wide frequency range: 20 MHz to 1000 MHz
High output power: 50 Watts
Excellent gain: 47 dB for strong signal amplification
Compact and lightweight design: 162.56 x 86.36 x 27 mm
Operates on 28 Volts and 8 Amps for efficient power usage
Supports CW, FM, and AM modulation types
Ideal for communication, industrial, and military RF systems
Reliable performance for continuous operation across various environments
The INS3153 Broadband Amplifier is a high-performance RF power amplifier designed for applications that require reliable and efficient amplification over a wide frequency range. Covering frequencies from 20 MHz to 1000 MHz, this amplifier delivers a powerful 50 Watts output with a robust 47 dB gain, making it an ideal solution for demanding environments where consistent signal strength and integrity are critical. Operating at 28 Volts and drawing 8 Amps of current, the INS3153 is engineered for stability and efficiency in continuous wave (CW), frequency modulation (FM), and amplitude modulation (AM) systems.
With a compact footprint of 162.56 x 86.36 x 27 mm, the INS3153 is suitable for both benchtop setups and system integration in confined spaces. Its versatile broadband coverage and rugged build make it a preferred choice for communications, test and measurement, industrial, and military applications. Whether you are building RF test equipment or enhancing signal coverage in a communication system, the INS3153 offers dependable performance and seamless integration.
| INS3153 Broadband Amplifier – Specifications | |
|---|---|
| Frequency Range | 20 MHz to 1000 MHz |
| Output Power (Pout) | 50 Watts |
| Gain | 47 dB |
| Operating Voltage | 28 Volts |
| Current Consumption | 8 Amps |
| Dimensions | 162.56 mm x 86.36 mm x 27 mm |
| Modulation Types Supported | CW, FM, AM |
| Application | Broadband RF amplification for communications, test systems, and industrial uses |
| INS3153 Broadband Amplifier – Included Accessories | |
|---|---|
| Accessory | Description |
| Power Supply Cable | Shielded cable suitable for 28V operation, ensures safe and stable power delivery |
| Mounting Brackets | Custom-fit brackets for secure installation in rack or benchtop setups |
| RF Input/Output Connectors | Standardized connectors (SMA/N-type based on configuration) for easy integration |
| Cooling Plate or Heatsink (Optional) | Passive cooling accessory to maintain optimal operating temperature during extended use |
| User Manual | Comprehensive guide covering installation, operation, and safety instructions |
| Test Report (Optional) | Factory-certified performance report upon request for quality assurance and compliance |
